WECON Technology LX5V-1412MT-AN

The WECON LX5V-1412MT-AN is a high-performance PLC module designed for advanced automation applications. It features:

• Input/Output channels: 14 inputs, 12 transistor outputs
• Supports high-speed pulse input and output
• Maximum pulse output frequency: 200 kHz
• Supports trapezoidal and S-type acceleration/deceleration
• Power supply: AC or DC
• Dielectric withstand voltage: 500V AC, 1 minute (between all terminals and ground)
• Execution speed: 0.01-0.03 µs per instruction
• Supports up to 100 high-speed counter interrupts
• Efficient and stable PID and CCPID self-tuning
• Compatible with LX3V series modules
• Supports E-CAM and electronic gear
• System storage: 512KB
• Program capacity: 48,000 steps
• Highest baud rate: 921600
• Supports 8-channel external interrupt with rising and falling edges
• Supports 100µs high-speed timer interrupt

This module is ideal for applications requiring precise control and high-speed processing in industrial automation systems.

5V series 14-in 12-out transistor type host with RS485 interface. It can be connected to a BD board, and can be connected to a PLC expansion module with an Ethernet port. https://youtu.be/1mrnY6vnA1Y?si=IRVre3SgCxesmhKl

WECON Reference Materials https://www.we-con.com.cn/en/product_page/2474.html
